General
Razeen® LR 1100 is a general purpose unmodified epoxy resin based on Bisphenol A
with medium viscosity.
Applications
Razeen® LR 1100 is widely used in 2-pack amine, polyaminoamide and heat (acid)
cured formulation. The main application are in highly chemical resistant coatings, civil
engineering, matrix adhesives, composites as well as in the fields of electrical insulation
and filament winding for manufacturing large diameter pipes.
Properties
- Medium viscosity and high reactivity
- Compatible with various hardeners, reactive diluents and accelerators
- Low hydrolysable chlorine content and therefore slight tendancy to crystalise at low
temperature.
- Conforms to FDA listing (food additives)
The resins formulated yield:
- Superior mechanical and electrical properties
- Excellent chemical and water resistance
Specific Key Data
| Property |
Value |
Test method |
| Appearance |
Clear, no contamination |
JCTM-001 |
| Color, APHA |
100 max |
ASTM D-1209 |
| Epoxy value |
5.20 - 5.49 eq/Kg |
ASTM D-1652 |
| Weight per epoxide |
182 - 192 g/eq |
ASTM D-1652 |
| Viscosity at 25oC (77oF)* |
11.000 - 14.000 mPa.s |
ISO 12058-1 |
| Hydrolysable Chlorine |
<500 ppm |
JCTM 195 |
| Water Content (KF) |
0.08% max. |
ASTM D-4017 |
| Specific key data are individually checked throughout, guaranteed and included in certificate of analysis. |
Typical Key Data
| Residual Epichlorohydrin |
5.0 ppm max |
JCTM GC6010 |
| Density at 25oC (77°F) |
1.16 g/cm3 |
ISO 1675 |
| Flash point |
≥ 200oC |
ISO 2719 |
|
Typical key data are spot-checked; the values are typical for the product and are indicated for
information only. The values are not included in certificate of analysis.
|
|
As-supplied form
|
Liquid |
|
Odor
|
None |
|
Shelf life (at storage temperature between 10-50°C)
(see expiry date on original container))
|
6 years |
|
Hazardous decomposition products
(when disposed of in fire)
|
Carbon monoxide, carbon dioxide
and other toxic gases and vapor |
|
Disposal
|
Regular procedures approved by
local authorities. |
Package and Storage
Razeen® LR 1100 is supplied in bulk and in 240 kg. steel drums. This product has a
minimum shelf life of six years when stored in unopened sealed containers in a dry
location at room temperature. Like most liquid epoxy resins, Razeen® LR 1100 may
crystallise when stored below room temperature. Heating the resin to 60-70°C (140-
160°F), for several hours will re-liquefy it and restore its original properties.
Tariff Number
39073000
Handling Precautions
Warning: Causes irritation.
May cause allergic skin reaction.
Avoid contact with eyes, skin or clothing.
Avoid breathing vapor, mist or spray.
Use with adequate ventilation.
Promptly remove wet, contaminated clothing and wash before reuse.
Wash after handling.
Store in a cool, dry area in closed containers.
Please read Safety Data Sheet before using.
Note
Razeen® is a registered trademark of JANA or an affiliate thereof.
