General
Razeen® SR 5097 is a solid, unmodified epoxy resin based on Bisphenol A.
Applications
Razeen® SR 5097 is a solid, high melt viscosity, epoxy resin designed for high quality
industrial coatings and for thick-film powder coatings. These typical applications are:
- Metal decorating finishes
- Can and coil coatings
- Drum and tank linings
- Application primers and enamels
- Metal furniture finishes
- Primers (including weldable primers) for practically all types of substrates
Razeen® SR 5097 is successfully used for the production of powder coatings for:
- Components used in the chemical industry with high chemical and mechanical
resistance.
- Tube and pipe coatings
Properties
- Superior flow and wetting properties
- High gloss development with reduced pigment floating and flocculation
- Good chemical, solvent and water resistance
- Outstanding adhesion and flexibility (impact resistance)
- Good corrosion resistance
- Excellent sterilisation performance
- Good deep-drawing capability
- Complies with the requirements of the FDA listing
Specific Key Data
| Property |
Value |
Test method |
| Appearance |
Clear, no contamination |
JCTM-002 |
| Color, Gardner* |
3 max |
ASTM D-1544 |
| Epoxy value |
0.52 - 0.66 eq/Kg |
ASTM D-1652 |
| Weight per epoxide |
1515 - 1920 g/eq |
ASTM D-1652 |
| Melt viscosity at 77oC |
1070 - 1760 mPa.s |
ISO 12058-1 |
* 40% in butyl carbitol
Specific key data are individually checked throughout, guaranteed and included in certificate of analysis. |
Typical Key Data
| Softening point (Mettler) |
100 - 118°C |
ASTM D-3461 |
| Density at 25oC (77°F) |
1.2 g/cm3 |
ISO 8130 |
| Hydroxyl content |
~ 3.2 eq /kg |
ISO 4629 |
| Flash point |
≥ 200oC |
ISO 2719 |
|
* 40% in butyl carbitol
Typical key data are spot-checked; the values are typical for the product and are indicated for
information only. The values are not included in certificate of analysis.
|
|
As-supplied form
|
Flakes |
|
Odor
|
None |
|
Shelf life (stored in proper temperature between
2 – 40°C) (see expiry date on original container))
|
6 years |
|
Hazardous decomposition products
(when disposed of in fire)
|
Carbon monoxide, carbon dioxide
and other toxic gases and vapor |
|
Disposal
|
Regular procedures approved by
local authorities. |
Package and Storage
Razeen® SR 5097 is supplied in 25 Kg. bags. This product has minimum shelf life of 6
years when stored in a dry place at room temperature. If stored under warmer
conditions, sintering may occur.
Tariff Number
39073000
Handling Precautions
Caution! Avoid dusty conditions.
Avoid contact with eyes.
Avoid breathing dust.
Avoid prolonged or repeated contact with skin.
When poured, resin can generate static electricity sparks which can ignite flammable
vapors or dusts.
Use with good ventilation.
Please read our Safety Data Sheet before using.
For Industrial use only.
First Aid
In case of contact:
Eyes : Promptly flush with water for at least 5 minutes.
Skin : Wash with mild soap and water.
Inhalation : Remove to fresh air. Give oxygen if breathing is difficult.
Ingestion : If conscious, give plenty of water. Call a physician.
Note
Razeen® is a registered trademark of JANA or an affiliate thereof.
